Pb Acid to Iron-lithum
Lead Acid Replacement Battery
HT-12V120Ah
Lead Acid Replacement Battery
Model
HT-12120
Nominal Capacity
120Ah
Nominal Energy
1536Wh
Nominal Voltage
12.8V
Charging Voltage
14.6V
Discharge Voltage
12V
Product Details
LeadAcid Replacement Battery
LiFeP04 Battery Pack
HT-12V120Ah
·Super long lifespan over 30oocycles
·Smaller size,lighter weight,higher energy density, environmentally friendly
·Wide working temperature range, better temperatureperformance
·High efficiency, energy saving,stable power supply,high power output
·Support configuration of communication function to fulfil intelligent management
TechnicalParameter；
| Cell | 3.2V62Ah |
| Cell Series & Parallels | 4S2P |
| Charge Current | 100A |
| Discharging Current | 100A |
| Max. Discharge Current 2S | 200A |
| Max Discharge Power | 1000w |
| Operating Temperature | Charge0-50C;Discharge-20-60 C |
| Cycle Life | ≥3000 Time |
| IP Class | IP50 |
| Dimensions | L330*W172*H215 mm |
| Weight | 12kg |
| Certificate | CE/FCC/UN38.3/MSDS |
