Pb Acid to Iron-lithum
Lead Acid Replacement Battery
HT-12V200Ah
Lead Acid Replacement Battery
Model
HT-12200
Nominal Capacity
200Ah
Nominal Energy
2560Wh
Nominal Voltage
12.8V
Charging Voltage
14.6V
Discharge Voltage
12v
Product Details
Lead Acid Replacement Battery
LiFeP04 Battery Pack
HT-12V200Ah· Super long lifespan over 3000cycles
· Smaller size,lighter weight,higher energy density,environmentally friendly
· Wide working temperature range, better temperature performance
· High efficiency, energy saving,stable power supply,high power output
·Support configuration of communication function to fulfil intelligent management
TechnicalParameter；
| Cell | 3.2V100Ah |
| Cell Series & Parallels | 4S2P |
| Charge Current | 200A |
| Discharging Current | 200A |
| Max. Discharge Current 10S | 400A |
| Max Discharge Power | 2000w |
| Operating Temperature | Charge0~50C;Discharge-20-60C |
| Cycle Life | ≥3000 Time |
| IP Class | IP50 |
Dimensions | L522*W240*H218 mm |
| Weight | 20kg |
| Certificate | CE/FCC/UN38.3/MSDS |
