Pb Acid to Iron-lithum
Lead Acid Replacement Battery
HT-12V150Ah
Lead Acid Replacement Battery
Model
HT-12150
Nominal Capacity
150Ah
Nominal Energy
1920Wh
Nominal Voltage
12.8V
Charging Voltage
14.6V
Discharge Voltage
12v
Product Details
Lead Acid Replacement Battery
LiFeP04 BatteryPack
HT-12V150Ah
· Super long lifespan over 3000cycles
· Smaller size,lighter weight,higher energy density,environmentally friendly
. Wide working temperature range, better temperature performance
·High efficiency, energy saving,stable power supply,high power output
· Support configuration of communication function to fulfill inteligent management
TechnicalParameter；
| Cell | 3.2V150Ah |
| Cell Series & Parallels | 4S1P |
| Charge Current | 100A |
| Discharging Current | 100A |
| Max. Discharge Current 10S | 200A |
| Max Discharge Power | 1000w |
| Operating Temperature | Charge0~50'C；Discharge-20~60 C |
| Cycle Life | ≥3000 Time |
| IP Class | IP50 |
| Dimensions | L330*W172*H215 mm |
| Weight | 13kg |
| Certificate | CE/FCC/UN38.3/MSDS |
